1

Optional control system

2

Maximum machining diameter

?20mm

3

There is a guide sleeve one-time clamping maximum processing length

Effective stroke 220mm

4

One-time maximum machining length without guide sleeve

50mm

5

Whether the guide sleeve switch function

Same selection function

6

Maximum drilling depth for the end face of the main shaft

7

Spindle through hole diameter

?21mm

8

Spindle rotation speed

6000rpm

9

S1 Side rotation power head of spindle

1 Drive 5 insert and pull type end face power head hole ER16 power head, spindle plug and pull end face power head 1 drive 3 ER16

10

S2 back spindle tool

4 two-way fixed cutting tools

11

Maximum collet diameter of back spindle

?20mm

12

Maximum bore diameter of back spindle end face

?10mm

13

Number of tool installation

13

14

Row cutting tool for turning

6

15

Side rotating tool

4

16

Front drilling tool

3

17

Backside drilling tool

3

The serial number

Cutter size

17

Tool (turning tool specification)

¨12*12mm

18

Chuck, guide sleeve

19

Spindle spring chuck

BO 20

20

Guide bush

BO 20

21

Back spindle spring chuck

BO 20

22

Side rotating tool chuck

23

Chuck for drilling sleeve

ER16

The serial number

Fast feed speed

24

X1 Y1 Z1 Z2

30m/min

25

The serial number

The motor

26

Spindle motor

7kw

28

Rotary tool motor

1kw

29

Back spindle motor

7kw

30

Axis motor

750kw

31

Center height

1020mm

32

The power capacity

16kva

33

Air pressure required by a pneumatic device

0.6mpa

34

The machine weight

2000kg

35

Overall dimension of the machine (length * width * height)

200*1200*170（mm）

36

volume

135L
