1

Standard NC control system

2

Maximum machining diameter

?7mm

3

Maximum machining length (1 time clamping)Maximum travel without guide sleeve

200mm

4

Maximum travel without guide sleeve

100mm

5

Maximum diameter of drill hole on the end face of the main shaft

?5mm

6

Maximum drilling depth for the end face of the main shaft

40mm

7

Spindle through hole diameter

?10mm

8

Spindle rotation speed

8000rpm

9

Maximum tool diameter for rotating tool

?7mm

10

Maximum tool diameter for rotating tool

5500rpm

11

Maximum collet diameter of back spindle

?7mm

12

Number of tool installation

16

13

Row cutting tool for turning

7

14

Side rotating tool

5

15

Front drilling tool

4

16

Backside drilling tool

4

The serial number

Cutter size

17

Tool (turning tool)

7mm*6

18

Chuck, guide sleeve

19

Spindle spring chuck

STAR7

20

Guide bush

STAR7

21

Back spindle spring chuck

22

Side rotating tool chuck

ER11*3

23

Chuck for drilling sleeve

ER11

The serial number

Fast feed speed

24

X1 Y 1 Z1

30m/min

25

The serial number

The motor

26

Spindle motor

2kw

27

Rotary tool motor

0.4kw

28

Back spindle motor

2.9kw

29

The axial motor

850kw

30

Center height

1050mm

31

The power capacity

3kva

32

Air pressure required by a pneumatic device

0.6MPa

33

The machine weight

1200kg

34

Overall dimension of the machine (length * width * height)

200*105*160（cm）

The serial number

Tank volume

155L

35

Main Standard Accessories

Special selection accessory

36

Cutting tool detection device

Fixed guide sleeve device

37

Spindle locking device

Spindle end power head

38

Short piece conveyor belt

39

Synchronous return transduction sleeve device

Y2 axis side power head

40

No guide sleeve device

Cooling system (2.5MP)

41

Spindle side power head

Oil mist collection system

42

Cutting cooling system

Chain board chip eliminator

43

Centralized lubrication system

Long piece tube type material receiving device
