1

Standard NC control system

Taiwan new generation/Yuanjie custom

2

Maximum machining diameter

?26mm

3

Maximum machining length (1 time clamping)

280mm

4

Maximum travel without guide sleeve

65mm

5

Maximum diameter of drill hole on the end face of the main shaft

?11mm

6

Maximum drilling depth for the end face of the main shaft

50mm

7

Spindle through hole diameter

?28mm

8

Spindle rotation speed

10000rpm

9

Maximum tool diameter for rotating tool

?11mm

10

Maximum tool rotation speed

5500rpm

11

Maximum collet diameter of back spindle

?26mm

12

Maximum bore diameter of back spindle end face

?11mm

13

Back spindle rotation speed

10000rpm

14

Number of tool installation

26

15

Row cutting tool for turning

7

16

Side rotating tool

5

17

Front drilling tool

4

16

Backside drilling tool

5

17

Backside rotary tool

5

The serial number

Cutter size

18

Tool (turning tool)

?12mm*7

19

Spindle spring chuck

BU26

20

Guide bush

BU26

21

Back spindle spring chuck

BU26

22

Side rotating tool chuck

ER16

23

Chuck for drilling sleeve

ER16

The serial number

Fast feed speed

24

X1/Y1/X2/Z2

30m/min

25

Y2

24m/min

The serial number

The motor

26

Spindle motor

2.2/3.7kw

27

Rotating spindle motor

0.75kw

28

Back spindle motor

2.2/3.7kw

29

Axis motor

0.85kw

30

Center height

990mm

31

The power capacity

12KVA

32

Air pressure required by a pneumatic device

0.6MPa

33

The machine weight

3150Kg

34

Overall dimension of the machine (length * width * height)

255*130*170cm

35

Mail volume

135L
